Table 24: PROFIsafe Group (G7.4.2.4)
Index
Parameter
Min
Max
Unit
Default
ID
Description
V7.4.2.4.1
Safety Telegram
–
–
–
–
–
Shows the number of the used telegram. Values:
ST 30
ST 31
ST 58000
V7.4.2.4.2
F-Par SRC Addr
–
–
–
–
–
Shows the value of F Source Address
V7.4.2.4.3
F-Par DEST Addr
–
–
–
–
–
Shows the value of F Destination Address
V7.4.2.4.4
F-Par WD Time
–
–
–
–
–
Shows the value of F WD Time
Table 25: File Info Group (G7.4.2.5)
Index
Parameter
Min
Max
Unit
Default
ID
Description
V7.4.2.5.1
File Name
–
–
–
–
–
Shows the first 12 characters of parameter File name
V7.4.2.5.2
File Creator
–
–
–
–
–
Shows the first 12 characters of parameter File creator
V7.4.2.5.3
Company Name
–
–
–
–
–
Shows the first 12 characters of parameter Company (Parame-
ter file)
V7.4.2.5.4
CRC
–
–
–
–
–
Shows the CRC of the used parameter file in hex format
V7.4.2.5.5
CRC integer
–
–
–
–
–
Shows the CRC of the used parameter file in decimal integer
format
Table 26: Diagnostics Group (G7.4.2.6)
Index
Parameter
Min
Max
Unit
Default
ID
Description
V7.4.2.6.1
Last Error Code
–
–
–
–
–
Shows the number of the last fault of the Advanced safety op-
tion board in hex format.
V7.4.2.6.2
SW Version
–
–
–
–
–
Shows the software version of the Advanced safety option
board.
V7.4.2.6.3
HW Version
–
–
–
–
–
Shows the hardware version of the Advanced safety option
board.
V7.4.2.6.4
FPGA Version
–
–
–
–
–
Shows the FPGA version of the encoder interface board on the
Advanced safety option board.
3.8.4 Fault Types
The Advanced safety option board has different fault types: critical fault, resettable fault, violation, and warning. The fault types of
the Advanced safety option board are not the same as the fault types of the AC drive. For more details on faults, see 12.1 Presenta-
tion of Faults on the Control Board.
AQ319736045637en-000101 / DPD01798 | 49Danfoss A/S © 2021.06
Overview of the System
VACON® NXP Advanced Safety Options
Operating Guide
