Use this parameter to set the minimum time for the speed to decelerate from Ramp1
Speed to zero.
Use this parameter to set the maximum time for the speed to decelerate from
Ramp1 Speed to zero.
Use this parameter to set the nominal speed that is used to define the ramp 2.
Use this parameter to set the minimum time for the speed to accelerate from zero to
Ramp2 Speed.
Use this parameter to set the maximum time for the speed to accelerate from zero to
Ramp2 Speed.
Use this parameter to set the minimum time for the speed to decelerate from Ramp2
Speed to zero.
Use this parameter to set the maximum time for the speed to decelerate from
Ramp2 Speed to zero.
8.1.5 Estimated Speed Parameters
Table 67: Estimated Speed Parameters
Use this parameter to set the time that it is estimated for the motor to coast to stop after
the drive stops operating. The set value must be maximum 3 hours.
8.2 Safe I/O Parameters
8.2.1 Digital Input/Output Parameters
Table 68: Digital Input/Output Parameters
Digital Input 1
Digital Input 2
Digital Input 3
Digital Input 4
STO(+SBC)
SS1
SS2 + SOS
SQS
SLS input 1
SLS input 2
SSR
SSM
SMS
SS1 Ramp
SS2 Ramp
Acknowledgment
Reset
Acknowledgment + Reset
Use this parameter to select the func-
tion for a digital input.
The configuration of an input is disa-
bled if a proximity sensor is used for
that input. Digital Input 1: one proxim-
ity sensor, and Digital Input 1 & 2: two
proximity sensors.
SSM
SBC
Group 1
Group 2
Group 3
Use this parameter to select the func-
tion for the digital output.
AQ319736045637en-000101 / DPD01798 | 127Danfoss A/S © 2021.06
Parameter List
VACON® NXP Advanced Safety Options
Operating Guide
