N O T I C E
Only compatible parameter files are taken into use on the option board. If the data in the backup location is faulty and sent to the
option board, the option board detects the faultiness. The STO function stays active until a valid parameter file is provided.
3.7.1 Storing a Parameter File Backup
Use these instructions to store a parameter file backup from the Advanced Safety Option.
Procedure
Find parameter P7.4.1.1.3 Save Backup To under the menu group G7.4.1.1 Config Settings.
Select a backup location with parameter P7.4.1.1.3.
Make sure that the parameter file backup was stored successfully.
Make sure that the parameter file is also stored on the PC.
Do factory reset for the Advanced safety option board.
Do a parameter restore from the backup location.
3.7.2 Restoring a Parameter File from Backup
Use these instructions to restore a parameter file from a backup into Advanced Safety Option.
N O T I C E
When the parameter file is restored from backup, the passwords are reset to the default.
Procedure
Find parameter P7.4.1.1.4 Load Backup From under the menu group G7.4.1.1 Config Settings.
Select a backup location with parameter P7.4.1.1.4.
Make sure that the restored parameter file is accepted by the Advanced safety option board.
Make sure that the restored parameter file is the correct file.
Load and view the parameter file on VACON
®
Safe.
Check the parameter file CRC on the control panel.
Check the used safety functions on the control panel.
Check the parameter file creator and date on the control panel.
Set the passwords to the intended values if necessary.
3.8 Advanced Safety Options with the NXP Drive
3.8.1 Requirements
To use the Advanced safety option board with the VACON
®
NXP AC drive, obey these requirements.
Table 16: Required Drive Component Versions
Component
Version
Comment
The control board of VACON
®
NXP AC drive
Hardware: VB00761 B (141L8026) or newer
Software: NXP00002V198 or newer
The STO and ATEX option board (OPTAF)
Hardware: VB00328 E (141L7786) or newer
Check the safety levels of STO in the
product manual.
When a safe fieldbus is used, see also 7.1.1 Introduction to PROFIsafe for the fieldbus related requirements.
AQ319736045637en-000101 / DPD0179844 | Danfoss A/S © 2021.06
Overview of the System
VACON® NXP Advanced Safety Options
Operating Guide
