Warning in any safety function
Limit violation error in any safety function
8.3 Safe Fieldbus Parameters
8.3.1 PROFIsafe Parameters
Table 69: PROFIsafe Parameters
Use this parameter to select the safe fieldbus.
Use this parameter to set a codename between sender and recipient. The source ad-
dress must be unique within a subnet.
Use this parameter to set a codename between sender and recipient. The destina-
tion address must be unique within a subnet.
Use this parameter to set the PROFIsafe watchdog time in F-Device. See 7.1.5.2 PRO-
FIsafe Watchdog Time.
Use this parameter to select the safety telegram. See 7.1.6.4 Data Mapping for PRO-
FIdrive on PROFIsafe.
8.4 STO and SBC Parameters
Table 70: STO and SBC Parameters
Use this parameter to select if manual (external) acknowledgment is necessary to
deactivate the safety function after the request ends. If the selection is automatic,
the function is deactivated after the request ends.
Table 71: SBC Parameters
Use this parameter to enable the SBC safety function.
Use this parameter to select which safety function activates first when the conditions for activa-
tion apply. The second safety function activates after the time set with SBC t1. See the tables in
6.2.2.3 The STO Function Used with the SBC Function.
Use this parameter to set the delay between the activation of the STO and the SBC functions. See
the tables in 6.2.2.3 The STO Function Used with the SBC Function.
This parameter is only valid for the activation. The deactivation of the STO and the SBC functions
always occurs simultaneously.
Use this parameter to set the speed at which the first function, STO or SBC, activates. SBC Speed
is used with SS1 and SQS-SS1 safety functions.
When you use the value 0 for SBC Speed, and a non-zero value for Zero Speed, Zero Speed is
used instead as the condition for the first safety function to activate. See the tables in 6.2.2.3 The
STO Function Used with the SBC Function.
AQ319736045637en-000101 / DPD01798 | 129Danfoss A/S © 2021.06
Parameter List
VACON® NXP Advanced Safety Options
Operating Guide
