7.1.6.9 VACON Safety Control Word (VS_CW)
The standard S_STW1 and S_STW2 do not include all safety functions that are supported by the Advanced safety option board.
However, a vendor-specific VACON Safety Control Word provides a full access to the safety functions and some extra features over
fieldbus. The bit value 1 means that the signal is "non-active" and the value 0 means "active". All unused bits must be set to 0. Set-
ting their bit value to 1 will cause a fault.
Table 60: Description of VACON Safety Control Word (VS_CW)
Byte
Bit
Name/Signal
Description
Reference
0
0
STO Request
Safe Torque Off
6.2.2.4 The STO and SBC Signals
1
SS1 Request
Safe Stop 1
6.2.3.5 The SS1 Signals
2
SS2 Request
Safe Stop 2
6.2.4.6 The SS2 and SOS Signals
3
SQS Request
Safe Quick Stop
6.2.5.3 The SQS Signals
4
SSR Request
Safe Speed Range
6.3.4.4 The SSR Signals
5
SLS Request bit0
Safe Limited Speed. See Table 61.
6.3.2.5 The SLS Signals
6
SLS Request bit1
Safe Limited Speed. See Table 61.
6.3.2.5 The SLS Signals
7
–
–
–
1
0
–
–
–
1
–
–
–
2
SSM Request
Safe Speed Monitor
(1)
6.3.5.4 The SSM Signals
3
SMS Request
Safe Maximum Speed
6.3.3.3 The SMS Signals
4
–
–
–
5..7
–
–
–
2–4
0..7
–
–
–
5
0
SS1_Ramp_Select
Ramp selection (0 = Ramp1, 1 =
Ramp2) for SS1
(2)
6.2.3.5 The SS1 Signals
1
SS2_Ramp_Select
Ramp selection (0 = Ramp1, 1 =
Ramp2) for SS2
(2)
6.2.4.6 The SS2 and SOS Signals
2..5
–
–
–
6
INTERNAL_EVENT_ACK / Reset
Acknowledge safety fault buffer (1 -> 0
edge)
6.1.6 Reset of a Safety Function
7
ACK_SAFETY / Acknowledgment
Acknowledge safety function (0 -> 1
edge)
6.1.5.1 Acknowledgment of a Safety
Function
1
The SSM function can be parameterized to be always active. In this case, the selector bit has no function.
2
Only when the safety function is parameterized to use ramp selection from the fieldbus.
AQ319736045637en-000101 / DPD01798122 | Danfoss A/S © 2021.06
Safe Fieldbuses
VACON® NXP Advanced Safety Options
Operating Guide
