VACON 9
If necessary, acknowledge the safety function or reset the
violations if violations occurred.
7
Repeat the steps 3 to 6 for each safety function intended to
be used over the safe fieldbus.
This can be done as a part of the safety function tests listed
in following chapters.
Safe fieldbus tests have been executed and possible deviations
documented.
□
Notes:
3.7 Safety function tests
If this document was printed from the VACON
®
Safe tool after the parameterisation of the Advanced safety
option board, this chapter should list all the safety functions that are used in the option board. Examine
possible differences.
If a safety function is intended to be used from both a digital input and a fieldbus, test the safety function
with the both of them.
3.7.1 STO + SBC
Here you can find the testing instructions for the STO and SBC functions. Do the SBC steps if the SBC
function is used.
Step
Instructions
Comments
STO-1
Make sure that the drive is in READY state.
Make sure that no safety functions are requested.
SBC-1
Make sure that the mechanical brake is
deactivated.
Make sure that SBC Reached is deactivated in
the used status output:
- The physical output of the option board
- The safe fieldbus status message
STO-2
Activate the STO function from the desired source.
STO-3
Make sure that the drive is not in READY state.
Applicable faults are shown:
Warning: F30 SafeTorqueOff, subcode: 1.
Warning: F46 SafetyRequest, subcode: STO (1).
NOTE! The faults that are shown and their type (Fault or
Warning) depend on the settings of the AC drive.
