11 Technical Data
11.1 Safety Data
Table 86: General Safety Characteristics
Item
Value
Safety integrity level (SIL) (IEC 61508)
up to SIL3
Systematic capability (SC) (IEC 61508)
SIL3
Safety integrity level claim limit (SIL CL) (EN 62061)
SILCL3
Performance level (PL) (EN ISO 13849-1: 2015)
up to PLe
Category (Cat) (EN ISO 13849-1: 2015)
Cat 4
Hardware Fault Tolerance (HFT)
1 (1oo2)
Proof test interval (PTI)
20 years
(1)
Mission time / Lifetime (TM)
20 years
1
PTI is Mission time/lifetime. No proof test for the option board required during the lifetime.
When you use standard speed sensors, see 3.6.2 Standard Speed Sensors and Combinations.
Table 87: Detailed Safety Characteristics
Option board variant
(1)
PFH
d
[1/h]
PFD
avg
DC
avg
[%]
MTTF
d
[a]
SFF [%]
OPTBL
6.45 x 10
-11
5.61 x 10
-6
99
373
99
OPTBM
1.66 x 10
-9
1.45 x 10
-4
112
OPTBN
1.70 x 10
-9
1.49 x 10
-4
94
1
All the values in the table are worst case values for one safety function and are fulfilled in any valid configuration.
The values above are calculated with these assumptions:
MTTR = MTR = 0 h. When a failure is detected, the STO safety function becomes active.
The proof test interval is 20 years.
Table 88: Response Times
Technical item or function
Minimum
Typical
Maximum
Response time to safety function request
–
–
10 ms
Response time to violation of a safety function
–
–
–
(1)
1
The response time to a violation depends on these factors:
Pulse per rotation (PPR) of the speed measurement sensor. The response time is faster with a higher PPR value.
Actual speed at the time of the violation of the monitored speed limit. The response time is faster in higher speeds.
11.2 Safe Input/Output Data
Number of inputs: 4 logical (4x2 physical).
