Danfoss VACON OPTEA User Manual

Table 89: Safe Input Data
Technical item or function
Minimum
Typical
Maximum
Input Voltage (Active, logic 1)
–
24 V
30 V
Input Voltage (Inactive, logic 0)
-3 V
0 V
5 V
Input Current (Active, logic 1)
3.0 mA
–
5.5 mA
Input Current (Inactive, logic 0)
–
–
2.0 mA
Input Resistance
3 kΩ
–
–
Galvanic Isolation
No
Short circuit protected
Yes
Active -> Inactive Debounce time
4 ms
Inactive -> Active Debounce time
50 ms
Allowed discrepancy time of physical inputs in one logical input
–
–
500 ms
Conductor size/cross-section (AWG)
0.2 mm
2
(28)
1 mm
2
(18)
Number of outputs (general): 2 logical (2x2 physical).
Number of outputs (STO): 2 logical (2 physical).
Table 90: Safe Output Data
Technical item or function
Minimum
Typical
Maximum
Output Voltage (Active, logic 1)
17 V
24 V
27 V
Output Voltage (Inactive, logic 0)
–
0 V
5 V
Output Current (Active, logic 1)
–
–
100 mA (250 mA combined
(1)
)
Output Current (Inactive, logic 0)
–
–
0.1 mA
Galvanic Isolation
No
Short-circuit protected
Yes
Diagnostic test pulsing
Alternating between a simultaneous pulse and individual pulse sequences on each physi-
cal output. Delay of 10 ms between pulses.
Diagnostic test pulse length
–
200 µs
400 µs
Diagnostic test sequence interval
–
200 ms
–
Output channel discrepancy time
–
–
–
Conductor size/cross-section (AWG)
0.2 mm
2
(28)
–
1 mm
2
(18)
Output state in case of a fault
All outputs are inactive.
1
Combined maximum output current for the Digital Output (STO & normal) and 24V supply is 250 mA.
AQ319736045637en-000101 / DPD01798146 | Danfoss A/S © 2021.06
Technical Data
VACON® NXP Advanced Safety Options
Operating Guide
