Table 22: Digital I/O Group (G7.4.2.2)
Index
Parameter
Min
Max
Unit
De-
fault
ID
Description
V7.4.2.2.1
DI1
DI2
DI3
DI4
–
–
–
–
–
Shows the logical value of the option board digital input. Updated
only for inputs that have safety functions assigned.
0 = The input is inactive
1 = The input is active
- = The input is not used
V7.4.2.2.2
DO1
DO2
–
–
–
–
–
Shows the logical value of the option board digital output.
0 = The output is inactive
1 = The output is active
- = The output is not used
Table 23: Encoder Group (G7.4.2.3)
Index
Parameter
Min
Max
Unit
De-
fault
ID
Description
V7.4.2.3.1
Encoder
Type
–
–
–
–
–
Shows the encoder type specified in the parameter file. Values:
None
Increm. TTL
Increm. HTL
SinCos
V7.4.2.3.2
Estimated
Speed
–
–
–
–
–
Shows whether estimated speed is used in the parameter file. Val-
ues:
Not in us
In use
V7.4.2.3.3
Proximity
Sensor
–
–
–
–
–
Shows the number of used proximity sensors in use. Values:
None
1
2
V7.4.2.3.4
Encoder
Speed
–
–
rpm
–
–
Shows the average speed measured by the option board (encoder
and proximity sensors)
V7.4.2.3.5
Encoder
Freq
–
–
Hz
–
–
Shows the speed of the motor based on the encoder data.
