B1 = SS1
B2 = SS2
B3 = SQS
B4 = SSR
B5 = SLS1
B6 = SLS2
B7 = SLS3
B10 = SSM
B11 = SMS
SafetyFunction-
ReachedWord
Displays the reached status of the safety functions. Corresponds to the Reached signal of the
safety function.
0 = The safety function is not reached.
1 = The safety function is reached.
B0 = STO
B1 = SS1
B2 = SS2
B3 = SQS
B4 = SSR
B5 = SLS1
B6 = SLS2
B7 = SLS3
B10 = SSM
B11 = SMS
Displays various states of the Advanced safety option.
NOTE! The state is updated only for digital inputs and outputs that have a functionality as-
signed to them. Bits corresponding to unused digital inputs and outputs remain as "0" regard-
less of the actual state.
B0 = DIN1
B1 = DIN2
B2 = DIN3
B3 = DIN4
B4 = DOUT1
B5 = DOUT2
B6 = SSM_Above_Max_Limit
B7 = SSM_Below_Max_Limit
B8 = Acknowledge_Requested_DIN
B9 = Acknowledge_Requested_PLC
B10 = Acknowledge_Requested_ Drive
B11 = SS1_Ramp_Select
B12 = SS2_Ramp_Select
B13 = Reset_Requested_DIN
B14 = Reset_Requested_PLC
B15 = Reset_Requested_Drive
Displays the value of the estimated speed provided to the Advanced safety option.
EstimatedShaft-
FreqInvalid
If this value is other than 0, the Estimated Shaft Frequency is not currently being calculated and
provided to the Advanced safety option.
AQ319736045637en-000101 / DPD01798140 | Danfoss A/S © 2021.06
Operation and Maintenance
VACON® NXP Advanced Safety Options
Operating Guide
