Speed measurement configuration
Value
Encoder number of pulses
1024
Proximity sensor number of pulses
–
Proximity sensor duty cycle
–
Table 112: SQS Parameters
SQS parameters
Value
Acknowledgment Mode (SQS)
Automatic 1)
Manual 2)
SQS Type
SS1
SQS Monitoring
Time
SQS Ramp Monitoring
–
SQS t1
5.0 s
SQS td1
–
SQS td2
–
1) and 2) indicate alternative options. Use values marked with the same number.
When you use the safety-aware Multipurpose drive application, the ramp to stand still while the SQS-SS1 function is realized by the
drive application when SQS-SS1 Active is indicated by the Advanced safety option board. The ramp definitions for the controlled
ramp are taken from drive ramp 1.
The SLS speed limit is realized by the drive application when the SLS function is requested from the option board. The speed limit is
taken from the Advanced safety option board. Drive application limits the speed to 95% of the parameterized limit. Ramping below
the speed limit is realized by using drive ramp 1.
Table 113: Configuration in the Safety-aware Multipurpose Drive Application
Parameter
Value
P2.12.1 S Stop Response
Ramp 1
P2.12.2 SLS Response
Ramp 1
P2.4.1 Ramp 1 Shape
0
P2.1.4 Deceleration Time 1
4 s
AQ319736045637en-000101 / DPD01798 | 179Danfoss A/S © 2021.06
Configuration Examples
VACON® NXP Advanced Safety Options
Operating Guide
