Table 124: General Parameters
General parameters
Value
Drive Reset
Disabled
Drive Acknowledgment
Disabled
Table 125: SS1 Parameters
SS1 parameters
Value
Acknowledgment Mode (SS1)
Automatic
SS1 Monitoring
Time
SS1 Ramp Monitoring
–
SS1 t1
5.0 s
SS1 td1
–
SS1 td2
–
Table 126: Speed Measurement Configuration
Speed measurement configuration
Value
Encoder Type
Sin/Cos
Encoder power supply
15 V
Encoder reference signal
No reference signal
Encoder number of pulses
1024
Proximity sensor number of pulses
–
Proximity sensor duty cycle
–
Table 127: Safe Fieldbus Parameters
Safe fieldbus parameters
Value
Fieldbus type
PROFIsafe
F Source Address
4096
F Destination Address
13
F WD Time
30 ms
Safety Telegram
30
Table 128: Configuration in the OPTE5 Option Board
Fieldbus parameters
Value
Telegram type
Standard Telegram 1 (ST1)
Operate mode
2 = Bypass
When running PROFIdrive application in NXP, bypass mode must be selected in OPTE5. If extra process data items are needed, a
different telegram type with 4, 8, 12 & 16 process data items can be selected.
