4. Commands
UniSite-xpi User Manual 4-9
Quick Copy
The Quick Copy command allows you to load data from a master device
and program that device data into a target device quickly and easily.
Note: Before you use the Quick Copy command, you must first select a device.
To use the Quick Copy command, follow these steps:
1. Select the device that contains the data you are going to load. For
more information, see the explanation of the Select Device command
earlier in this chapter.
2. Select the Quick Copy command by pressing Q from the Main Menu.
The dialog window displays the Quick Copy screen. The message bar
displays the following message:
Insert master device. Hit return.
3. Insert the master device and lock it into place.
4. Press E
NTER to begin loading the master data into RAM. When the
data in the master device has been loaded, UniSite-xpi displays
OPERATION COMPLETE. Sumcheck = xxxxxxxx (8-bit) Hit
return
Note: (Legacy) If you are using the Quick Copy function with SetSite, you must
press Return again at this point. This allows you time to review the screen
and sumcheck information.
5. Remove the master device and press E
NTER. UniSite-xpi displays
Insert blank device. Hit return.
6. Insert the target device (the device you want to program) and lock it
into place.
7. Press E
NTER to program the device.
8. When the programming operation is complete, UniSite-xpi displays
OPERATION COMPLETE. Sumcheck = xxxxxxxx (8-bit) Hit
return
9. The Quick Copy operation is complete. Remove the device.
10. To program another device, return to step 6.
Note: (Legacy) If you are using the SetSite module, you may also use the Quick
Copy command to load data for gang programming. Data Word Width
will automatically be set to Device Word Width.
Main
Menu
Quick
Copy (pro-
gram
Quick
Copy
(load
