1. Introduction
UniSite-xpi User Manual 1-5
18. Terminal Port Connector—Connects UniSite-xpi to PCs,
workstations, terminals, file servers, etc.
19. Terminal Port DTE/DCE Selector—Configures the Terminal port as
Data Terminal Equipment or Data Communication Equipment.
Disks
Programmer Disks The Boot Files disk and the Algorithm/System disks are inserted in the
programmer’s disk drive. After setting up the programmer, make backup
copies of the Boot disk and Algorithm/System disks using disks
formatted on the programmer. Use the copies during daily operation.
Algorithm/System Disks Algorithm/System disks contain the system software and programming
algorithms for the currently supported devices. The UniSite-xpi is
shipped with the algorithm files already stored on the Mass Storage
Module (MSM).
(Legacy) For legacy UniSite, your algorithm files are not stored on the
Mass Storage Module, and one of the Algorithm/System disks must be
installed in the programmer disk drive each time you select a device. You
will be prompted for the specific disk to insert.
Boot Files Disk The Boot Files disk contains system software and configuration files used
to boot up the programmer.
PC Disk The Utility Disk is inserted in the floppy disk drive on your PC.
Utility Disk The Utility Disk contains HiTerm software for your PC. For more
information, see the manual.doc file on the Utility Disk.
