3. Getting Started
3-26 UniSite-xpi User Manual
Using Key Functions Some of UniSite-xpi’s functions may be performed by pressing a key or a
combination of keys. When using the C
TRL key, hold it down and then
momentarily press the second key. The key functions are listed below
with their corresponding keystroke sequence.
Review of
Programming
Concepts
Below is a brief description of the basic concepts involved in
programming a device.
Select Device Before attempting most operations, you must first tell UniSite-xpi what
device you will be working with. UniSite-xpi then selects the appropriate
programming algorithm based on the manufacturer and device part
number selected. Once you have selected a device, you can move on to
other device operations, such as loading, programming, and verifying.
Load Data Load operations determine how you move device data into UniSite-xpi.
You can load data from a device, from one of UniSite-xpi’s internal disk
drives, or from one of the two serial ports on UniSite-xpi (for example,
from the Remote port).
Program Device Programming transfers the device data into the device inserted in
UniSite-xpi. The programming is done according to the programming
algorithm selected by the Select Device command. The programming
operation also includes a verify operation, which is described below.
Keystrokes Description
F1
Return to the Main Menu
F2 Go to the previous menu
F3 or ? Display online help for the current menu and cursor
position
F4 Display the Optional Parameters screen
ENTER Execute highlighted command
SPACE Toggle a parameter
CTRL + N Display next page
CTRL + P Display previous page
CTRL + R Repaint screen
CTRL + Z Halt current operation
ESC CTRL + T Enter/exit transparent mode with host computer
ESC CTRL + J Start/stop job file recording
ESC CTRL + W Restart UniSite-xpi (warm boot)
