DIMENSIONING SETUP AND CALIBRATION
3. Click Update.
4. In Modify Settings | Tach/Trigger/Transmit, make sure:
Trigger Source is set to Application Specifications
Pulse per in [cm] (16ppi [6.4 pulses per cm] or 20ppi [8 pulses per cm]
should be set to match the tachometer switch setting
5. Click Update when you have finished making changes.
NOTE: The trigger reference point is in reference to
HEAD1 regardless of where HEAD2 is located (upstream
or downstream).
