TECHNICAL FEATURES
139
8
8 TECHNICAL FEATURES
8.1 TECHNICAL SPECIFICATIONS
DC3000 Dimensioning Controller
ELECTRICAL FEATURES
Power
Requirements
Minimum power input: DC 9 V ~ 34 V 9.0 A ~ 2.4 A
Communication
Interfaces
Ethernet 2 x RJ45 (TCP/IP), 2 x RS232, 1 x RS232/422/485
Inputs
6 x USB 2.0 compliant Ports
Video
VGA + DVI-D (Extended by DVI-I Y-cable), VGA + HDMI,
DVI + HDMI
USER INTERFACE
Programming
On board HTML web server interface
ENVIRONMENTAL FEATURES
Temperature
Operating: 0° to 50° C [32° to 122° F]
Storage: -40° to +85° C [-40° to +185° F]
Relative Humidity
95% @ 40° C (non-condensing)
PHYSICAL FEATURES
Overall Dimensions
L 267 mm [10.5”] x W 174 mm [7.0”] x H 124 mm [5.0”]
Weight
4.0 kg [8.8lb]
Enclosure
DM3610 Dimensioner
ELECTRICAL FEATURES
Power
Requirements
24VDC +/- 10%
Power Consumption
19 W Average (75 W Max) based on 600 scans/second
Communication
Interfaces
Ethernet (TCP/IP), RS232/ RS422 (RS485 for custom only)
Inputs
(1) Tachometer, (1) Trigger, (2) SW programmable general purpose
OPTICAL FEATURES
Wavelength
Visible laser diode (red) 658 nm typical
Safety Class
Class 3R – IEC60825-1; Class II - CDHR
DIMENSIONING FEATURES
Dimensioning
Accuracy
• NTEP/
± 0.20” for length and width and ± 0.10” for height
• OIML
± 5.0 mm for length, width and height
Conveyor Speeds
Up to 3.1 m/s [620 fpm]
