2.2 INSTALLATION SEQUENCE
NOTE: Everything should be MECHANICALLY INSTALLED before
performing any ELECTRICAL INSTALLATION.
See chapter 3 for electrical installation details.
To complete mechanical installation and setup, you must:
 Review the details of your application’s requirements
 Erect mounting structure or other supporting structures
 Determine and mark the Universal Mounting Brackets (UMB) locations
 Mount the UMB Mounting Plates to the UMBs (if not already installed)
 Mount the UMBs to the mounting structure
 Change the default parameters each DM3610 in the system to include a unique name,
IP Address, and other parameters (See 2.4.12)
 Mount the DM3610 dimensioners to their UMBs
 Mount the photoelectric sensor to the mounting structure (optional)
 Mount the tachometer to the mounting structure (optional)
 Mount the Remote Display to the mounting structure (required for Legal-for-Trade
installations, dependent on requirements)
 Mount the CBX510 connection box to the mounting structure
 Mount the DC3000 Controller to the mounting structure
 Complete electrical installation (See chapter 3)
 Align the DM3610 dimensioners for proper operation
 Calibrate the DM3610 dimensioners (See chapter 5)
 Configure the DC3000 Controller (See chapter 4)
 Check system operations (See chapter 5)
