MECHANICAL INSTALLATION
23
2
Figure 23: Securing the UMB to the structure
Figure 24: Securing the UMB to the structure (Alternate)
Set
Screws
Threaded
Inserts
UMB
Mounting
Disk
Mounting
Line
Pitch Angle
Adjustment
nuts
Set
Screws
Threaded
Inserts
UMB
Mounting
Disk
Mounting
Line
Pitch Angle
Adjustment
nuts
