TWO-HEAD DIMENSIONING SYSTEM REFERENCE MANUAL
When selected, the dimensioner is always in trigger mode
and immediately transmits the dimensions of any package
seen.
Transmit is hidden if Continuous Trigger is selected as the trigger source.
Specifies which edge of the package (leading or trailing) is used to reference
the transmit point.
This input is only visible when DIM-in-Head Enabled is set to On in Modify
Settings | Dimensioning | Settings. The point at which dimension data is
transmitted. Defines the number of inches or centimeters after the specified
edge of the package passes the trigger before data transmission occurs.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values.
