TWO-HEAD DIMENSIONING SYSTEM REFERENCE MANUAL
2. Select the appropriate information in the form as described below.
Select a baud rate from the options provided (signal events per second).
Select the number of data bits from the options provided (bits per second).
Select the number of stop bits from the options provided.
Select a parity option of None, Even, or Odd.
Select a message format from the drop-down list:
Custom Message: Custom messaging is enabled here if your application
uses custom software.
Standard Message: The standard message format begins with a (STX)
character and ends with a (CR)(LF).
NOTE: When Standard Message is selected, no
user input is permitted in the Message Definition #n
window.
User-Defined Message: Use the Message Definition form to specify your
message format.
Legal for Trade: Select this option to use an external display device for
certified dimensioning.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values.
