Datamax M-Class Mark II Maintenance Manual

Adjustments and Maintenance
2-16
Step Action Displayed Message Comment
8
Use the buttons to set
the Gain Number to 00
and then press ENTER.
Record the sensor
reading as a Label
Value for Gain Number
00 in a table (32 rows
by four columns, with
headings similar to
those shown below.)
TRAN SENSOR GAIN
yyy (0 - 31)
00
This is the Label Value for a
gain setting of 00, where
“yyy” represents the current
sensor reading.
Sample Calibration Table
Gain Number Label Value TOF Value Difference Value
00 252
01
02
…
31
Step Action Displayed Message Comment
9
Use the buttons to
increment the Gain
Number by one and
then press ENTER.
Record the Label Value.
Repeat this process for
each Gain Number.
TRAN SENSOR GAIN
yyy (0 - 31)
01
Remaining Label Values,
where “yyy” represents the
current sensor reading.
Sample Calibration Table
Gain Number Label Value TOF Value Difference Value
00 252
01 250
02 248
……
31 09
(continued)

Datamax M-Class Mark II Specifications

General

Media Sensor	Adjustable reflective and transmissive sensors
Print Method	Thermal Transfer
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Interface Options	USB, Serial, Ethernet, Parallel
Media Type	Roll-fed, die-cut, continuous, fan-fold, tags, ticket stock
Media Width	1.0 in (25.4 mm) to 4.65 in (118 mm)
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Media Roll Diameter	8 inches (203 mm) max
Ribbon Width	1 to 4.33 inches (25.4 to 110 mm)
Ribbon Length	1968 ft (600 m)
Ribbon Core	1 inch (25.4 mm)
Label Width Range	1.0 in (25.4 mm) to 4.65 in (118 mm)
Label Length Range	0.25 to 39 inches (6.35 to 991 mm)
