Adjustments and Maintenance
2-17
Step Action Displayed Message Comment
10
Raise the printhead
assembly then proceed
according to the media
type:
• Die-cut: Peel labels
from the backing
then insert the
backing under the
Sensor Eye Mark;
• Notched: Insert the
notch under the
Sensor Eye Mark; or,
• Reflective: Insert the
black mark facedown
under the Sensor
Eye Mark.
TRAN SENSOR GAIN
yyy (0 - 31)
31
Do not position a perforation
in the Media Sensor; and if
using preprinted media,
ensure the label area placed
in the sensor is free of text,
graphics, lines, etc.
11
Lower and latch the
printhead assembly.
Set the Gain Number to
00 and then press
ENTER.
Record the reading as a
TOF Value for Gain
Number 00 in the table.
TRAN SENSOR GAIN
yyy (0 - 31)
00
This is the TOF Value for a
gain setting of 00, where
“yyy” represents the current
sensor reading.
Sample Calibration Table
Gain Number Label Value TOF Value Difference Value
00 252 248
01 250
02 248
……
31 09
(continued)
