Chapter 6 Description of Operations
PAGE 6-41
(Continued from previous page)
Item
D-No.
Contents
Setting
change
Units
Connected
Tool Settings
100
Connected Tool No.
101
Connected Tool Information “015-P1”
102
Connected Tool CAL Torque Decimal Point Position
103
Connected Tool CAL Torque
Nm
104
Connected Tool CAL Voltage
V
105
Connected Tool ZERO Voltage
V
106
Connected Tool Internal Gear Ratio (×100)
107
Connected Tool Serial No. (upper 3 digits)
108
Connected Tool Serial No. (lower 4 digits)
109
Connected Tool Rotation Direction
110
Connected Tool Order No. (upper 2 digits)
111
Connected Tool Order No. (lower 5 digits)
112
Connected Tool Cycle Count (×1 million)
113
Connected Tool Cycle Count (×1)
114
Connected Tool Maximum Current
A
Unit
Information 2
200
Unit Setting Tool No.
○
201
Unit Setup Tool Information “015M50”
202
Parameter Setting File Version
203
Sequence Setting File Version
204
PLC Output Layout Setting File Version
205
Fieldbus Setting File Version
206
Fieldbus Message Setting File Version
207
RS232C Input/Output Setting File Version
208
Unit RS232C-1 Communication Speed
bps
209
Unit RS232C-1 Parity
210
Unit RS232C-1 Stop Bit
bit
211
Unit RS232C-1 Word Length
bit
Option
Information1
300
Connected Fieldbus Information
301
ANYBUS-CC Version
302
Unit Setting Fieldbus Information
303
Station No. (Node Address) (1 ~ 64 or 0 ~ 63)
304
Communication Speed (0 ~ 4)
305
Occupied Stations (1, 2, 3, 4)
306
Extended Cyclic Setting (1, 2, 4, 8)
307
I/O Setting Byte Length “PLC ￫ MASTER Spindle”
308
I/O Setting Byte Length “Master Spindle ￫ PLC”
309
Message Block Byte Length
310
Message Setting Byte Length “PLC ￫ MASTER Spindle”
311
Message Setting Byte Length “Master Spindle ￫ PLC”
312
IP Address (upper 6 digits)
313
IP Address (lower 6 digits)
314
Subnet Mask (upper 6 digits)
315
Subnet Mask (lower 6 digits)
316
Gateway (upper 6 digits)
317
Gateway (lower 6 digits)
(Continued on next page)
