Chapter 4 Installation
PAGE 4-28
4-8. Ethernet Interface
The Ethernet interface is the TCP/IP Ethernet port dedicated to communication with the HFC3000
User Console installed in a PC with Windows
®
.
A commercially available LAN cable (cross/straight) can be used as the cable.
The following factory settings are set as the TCP/IP settings of the Unit. The settings at the PC side
must thus be changed when first connecting to the PC.
IP address
192.168.11.10 (factory setting)
Subnet Mask
255.255.255.0(factory setting)
Default Gateway
192.168.11.1 (factory setting)
Communication Protocol
IEEE 802.3 compliant
Ethernet Standard
100BASE-T
Communication Speed
100Mbps
Cable
Category 5 or higher (category 5 is recommended)
Connector Shape
RJ-45
