Chapter 6 Description of Operations
PAGE 6-5
③LED for judgment and status indications (4 LEDs):
During the fastening operation, all judgment LEDs are OFF.
If the fastening result is OK, the green judgment LED lights up.
(In the case of TOTAL OK, the green judgment LED flashes slowly.)
If the fastening result is NG (failure), the red judgment LED becomes lit (angle-related
NG: rapid flashing; torque-related NG: continuously lit up; other NG: slow flashing).
During initialization upon power activation, the orange judgment LED lights up.
If as a result of initialization, the tool does not recognize the Unit (communication
disconnected), rapid flashing in red is performed.
This flashes only while the CAL button on the operation panel is being pressed.
If the result of CAL check is OK: The LED flashes rapidly in orange <--> green.
If the result of CAL check is NG: The LED flashes rapidly in orange <--> red.
Besides the above, all LEDs are OFF if an error occurs.
* The orange color is made to appear by the green LED and the red LED lighting up
simultaneously (when viewed at a close distance, the red and green colors appear
separately).
6-3. Changing between RUN and PROGRAM Modes
There are two modes to the Handheld tool - the RUN (operation) and PROGRAM (setting) modes.
In the RUN (operation) mode, the fastening operation and the fastening result judgment are indicated.
Parameters can be changed in the PROGRAM (setting) mode.
Changing between the RUN and PROGRAM modes can be performed by the PLC I/F BYPASS signal
or the PRG key switch (long-pressing for 1.5 seconds).
