DDK HFC3000II - Indications in the PROGRAM Mode(Set Value Selection Mode)

Chapter 6 Description of Operations
PAGE 6-20
6-5-2. Indications in the PROGRAM Mode(Set Value Selection Mode)
Immediately after changing to the “Set Value Selection Mode,” the cursor (flashing number) is
indicated in the WORK indication part when the [◄] switch is pressed and is indicated in the
COUNT/D-No. indication part when the [►] switch is pressed.
When the [▲] or [▼] switch is pressed, the numerical value at the cursor position changes by ±1.
When the [►] switch is pressed, the cursor position moves to the COUNT/D-No. indication part.
Also, when the [◄] switch is pressed, the cursor position moves to the WORK indication part.
When the “SET” switch is pressed, changing to the “Set Value Editing Mode” is performed.
Set Value Editing Mode
SET
SET
SET
S0140185-H
