Chapter 9 External Interface
PAGE 9-27
9-5-3. I/O Signal Specifications
I/O Input/Output
Message Input/Output
Contorller to PLC
PLC to Contorller
Contorller to PLC
PLC to Contorller
Maximum
Setting
32 bytes (256 points)
8 bytes (64 points)
4096 bytes
32 bytes
Standard
Setting
16 bytes (128 points)
8 bytes (64 points)
200 bytes
32 bytes
9-5-4. Fieldbus Setup
In the Device Net window, setting of the Anybus-CompactCom Device Net is performed.
The communication speed, the node address, the I/O settings, and the message settings can be changed.
●Default (the settings are set to the factory settings)
･Node Address:0 ･Speed: 500k bps
･Setting I/O [PLC to Contorller]: 8bytes[64bits]
･Setting I/O [Contorller to PLC]: 16bytes[128bits]
･Message Bytes Settings[PLC to Contorller]: 32bytes
･Message Bytes Settings [Contorller to PLC]: 200bytes
* Message Block Bytes is fixed at 200 bytes.
●Node Address
Setting range: 0 ~ 63
●Speed
Setting range: 156kbps, 250kbps, 500kbps
●Setting I/O
･[PLC to Contorller]
Setting range: 2bytes [16bits] ~ 8bytes[64bits]
･[Contorller to PLC]
Setting range: 2bytes [16bits] ~ 32bytes[256bits]
●Message Bytes Settings
･[PLC to Contorller]
Setting range: 0byte ~ 32bytes
・[Contorller to PLC]
Setting range: 0byte ~ 4096bytes
