DDK HFC3000II - Input Signal: BANK SELECT

Chapter 4 Installation
PAGE 4-10
4-5-2. Input Signal : BANK SELECT
The following TB signal names will change according to the output status of TB 1-12
"BANK SELECT".
・Please turn OFF the input signal "BANKSELECT" during fastening operation and when
not using bank switching.
·After switching the BANK SELECT signal ON / OFF, wait for 20 msec or more before
inputting the output signal.
・BANK SELECT = OFF
TB
Signal
IN/OUT
Description of Function/Usage
2-1
REJECT[NG]
OUT-1(NO)
Set to “ON” when the fastening operation ends with a fastening
result falling outside a judgment range.
2-2
ACCEPT[OK]
OUT-2(NO)
Set to “ON” when the fastening operation ends with the fastening
results being within the judgment ranges.
2-3
ABNORMAL
OUT-3(NO)
Set to “ON” when an error occurs in the system or during the
fastening operation.
2-4
READY
OUT-4(NO)
Set to “ON” when operation is enabled with respect to an input
signal from the outside. This signal is also set to “ON” after the
end of fastening.
2-5
BUSY
OUT-5(NO)
Set to “ON” while the Spindle is in the fastening operation.
2-6
PROGRAM
OUT-12(NO)
Set to “ON” when the Unit is in the PROGRAM mode.
3-7
FASTENING
RESULT
DATA AVAILABLE
OUT-6(NO)
Set to “ON” when a fastening result is present in the Unit.
3-8
CF ERROR
OUT-7(NO)
With the controller with CF card option, out of the following
conditions. It turns ON when either one is satisfied.
· CF card not inserted
· CF card remaining capacity is 1% or less
(Controller software version V1.209 or earlier)
· CF card remaining capacity is less than 20 MB
(Controller software version V1.210 or later)
・BANK SELECT = ON
TB
Signal
IN/OUT
Description of Function/Usage
2-1
WORK OUTPUT BIT 5
OUT-1(NO)
It turns ON when 33 to 64 is selected as the parameter number.
2-2
Unused
OUT-2(NO)
Please do not use.
2-3
Unused
OUT-3(NO)
Please do not use.
2-4
WORK OUTPUT BIT 0
OUT-4(NO)
Return output of the select signals of WORK SELECT BITS 0～
4 is performed
2-5
WORK OUTPUT BIT 1
OUT-5(NO)
2-6
WORK OUTPUT BIT 4
OUT-12(NO)
3-7
WORK OUTPUT BIT 2
OUT-6(NO)
3-8
WORK OUTPUT BIT 3
OUT-7(NO)
Caution
S0140185-H
