Chapter 4 Installation
PAGE 4-9
(Continued from previous page)
TB
Signal
IN/OUT
Description of Function/Usage
3-1
IN COMMON
IN
Common input signal (bipolar)
3-2
+24V
OUT
DC24V SERVICE POWER SUPPLY 0.5Amax
3-3
GND
3-4
OUT COMMON
Common output signal (bipolar)
3-5
BATCH OK RESET
IN-13(NO)
OK count is initialized to 0,and turn off the TB2-9 [BATCH OK]
signal by setting this signal to “ON”
3-6
Unused
IN-14(NO)
Not connected internally
3-7
The name of the signal to be output changes according to the output status of TB 1-12 "BANK
SELECT".
(Reference 4-5-2. Input Signal: BANK SELECT)
3-8
3-9
Unused
IN-15(NO)
Not connected internally
(Controller software version V 1.300 or earlier)
WORK SELECT BIT 5
The WORK SELECT BIT 0 ～ 5 select signals enable selection
among parameter Nos. 1 ～ 64 by a combination of the 6 pin
Nos.
WORK SELECT BIT 0～4 is assigned to TB 1-7～11.
(Controller software version V1.301 or later)
3-10
Unused
IN-16(NO)
Not connected internally
(Controller software version V 1.300 or earlier)
ID SELECT ENABLE
WORK number selection by input ID becomes enable by setting
this signal to “ON”
(Controller software version V1.301 or later)
3-11
+24V
OUT
DC24V SERVICE POWER SUPPLY 0.5Amax
3-12
GND
S0140185-H
