Chapter 8 Options
PAGE 8-3
8-1-2. Selection criteria
●specification
・Data transfer method.：PIO Max 8.3MHz/byte *Initial CF card transfer standard。
・Capacity ：32GB or less
・Operating environment：0°~ 45°
・Function：With write distribution function
・FAT12、FAT16、FAT32 Format
●Operation confirmed CF card
・Manufacturer：Made by SanDisk, Greenhouse
8-1-3. CF ACCESS LED
Name
Color
States
CF
ACCESS
LED
Off
Competed save data
Green
Saving data
Formatting in progress
Orange *1
The storable capacity of the CF card falls to less than 200MB
(Capacity is 1 to 10% before Controller software version V1.209)
Red *2
CF card is not inserted
Failed to save data
Format failed
The storable capacity of the CF card falls to less than 20MB
(Capacity is 1% or less before Controller Software Version V1.209)
*1: if ”Formatting the CF card” is executed, to turn off CF ACCESS LED.
*2: It continues to light up until the unit's control power supply is turned on again
S0140185-H
