DDK HFC3000II - 2-1. System Specifications

Chapter 2 Specifications
PAGE 2-2
2-1. System Specifications
Power
Source
Voltage
Single-phase 100 to 240V AC ±10%
(5m cable for 125V AC provided as accessory)
Frequency
50/60Hz
Installation environment
No vibration must be applied directly to the Unit.
Forced-cooling equipment or heating equipment is required when
using the Unit outside the following operating range.
Operating
Conditions
Ambient
temperature
0°C to +45°C (Avoid freezing)
Ambient
humidity
No more than 90%RH (Avoid condensation)
Operation
range
Duty cycle: within 50% (within the prescribed time for one cycle)
See “2-1-1 Duty Cycle Calculation.”
Storage
Conditions
Ambient
temperature
-5°C to +55°C (Avoid freezing)
Ambient
humidity
No more than 90%RH (Avoid condensation)
Shipping
Conditions
Ambient
temperature
-5°C to +55°C (Avoid freezing)
Ambient
humidity
No more than 50%RH (Avoid condensation)
Packing
method
Tight seal
Ambience
Indoors (no direct sunlight), free from corrosive gas, flammable
gas, oil mist, dust, and dirt.
2-1-1. Duty Cycle Calculation
The duty cycle for HFC series is calculated as follows.
Duty Cycle (%) = Rotating time ÷ (Rotating time + Downtime) × 100
2-1-2. Unit Specifications
Unit model
HFC-B016
HFC-B024A
Motor model
M50,M80
M50,M80,M120
Power source voltage
Single phase 100 to 240V AC ±10%
Power source frequency
Both 50/60HZ
Power consumption rating
80W
120W
Maximum momentary current
11.3Ap
(at the time of motor max power)
19Ap
(at the time of motor max power)
Inrush current
38Ap/AC100V,76Ap/AC200V
Power supply capacity
1.2kVA
1.9kVA
Ground fault interrupter
(Sensitivity electric current)
⊿I 30mA Max
S0140185-H
