Chapter 8 Options
PAGE 8-2
8-1. CompactFlash
8-1-1. Summary
Fastening results and fastening curves can be stored as files in a CompactFlash card (hereinafter,
“CF card”). The stored data can be confirmed later by reading with a PC.
・ If an unused CF card or a CF card used in another device is to be used, be sure to
use it after formatting it.
●List of Number of Storable Data Sets According to Capacity
・Storage data format: Fastening results + Fastening curve (180 degrees: torque vs. angle)
Storage
Capacity
Number of Stored Data Sets
4GB
approx. 900 thousand sets
8GB
approx. 1.8 million sets
16GB
approx. 3.4 million sets
32GB
approx. 7.0 million sets
[Precautions Concerning CF Card Usage]
・When inserting / extracting a CF card, the power of the Unit is must be performed
in the state of OFF always.
・Be careful as the data stored in a CF card may be erased under the following
conditions.
♦When a user handles a CF card incorrectly.
♦When a CF card is used or stored in an environment with static electricity or
electrical noise.
♦When a CF card is not used for a long period of time.
・Be sure to back up the necessary data in a PC, etc., periodically.
・Avoid use and storage in a location with sudden temperature change, a location
where condensation occurs, or a location exposed to direct sunlight.
・Do not bend or apply a strong shocks to the CF card. Also, do not wet the CF card
with water or place it in a location of high temperature.
Caution
Caution
S0140185-H
