Chapter 5 Power Activation and Operational Tests
PAGE 5-4
5-3. Input Initial Setting Data
After checking all of the check items of the previous section and activating the power, input the data
necessary for performing fastening. Although initial setting data based on the customer’s
specifications are input at the time of shipment, if the setting data need to be changed, please refer
to “Chapter 6 Description of Operations.”
5-4. Items to be Checked After Activation
Perform the following checks after activating the power.
(1) Check ZERO Value
Press the RESET switch on the controller and confirm that a value close to zero is indicated as the
torque value on the controller. Also confirm that NG LED (red) does not light up at this point.
(2) Check CAL Value
Press the CAL switch on the controller and confirm that NG LED (red) does not light up.
(3) Check Rotation
Press the start switch on the tool to make the tool rotate and confirm that there is no abnormal noise
or rotational vibration, etc.
The tool should rotate only when the start switch is pressed and stop when the switch is released.
(4) Check Reverse Rotation
Press the reversing switch on the tool and confirm that the judgment LED flahses.
Then press the start switch. Reverse rotation should be performed while the switch is pressed.
Press the reversing switch again to put the tool in the fastening mode.
