Chapter 6 Description of Operations
PAGE 6-56
(Continued from previous page)
Item
D-No.
Contents
Torque
Method
Angle
Method
Rate
[N･m/deg]
Time [sec]
300
Rate 1 Low Limit
○
○
301
Rate 1 High Limit
○
○
302
Rate 2 Low Limit
○
○
303
Rate 2 High Limit
○
○
304
Rate 3 Low Limit
○
○
305
Rate 3 High Limit
○
○
310
Initial Time
○
○
311
1st Time Low Limit
○
○
312
1st Time High Limit
○
○
313
2nd Time Low Limit
○
○
314
2nd Time High Limit
○
○
315
Torque Recovery Time
○
○
316
1 Pulse Reverse Time
○
○
Speed
[rpm]
400
Initial Speed
○
○
401
Freerun Speed
○
○
402
1st Speed
○
○
403
2nd Speed
○
○
404
3rd Speed
○
○
405
Reverse 1 Speed
○
○
406
Reverse Speed between 1-2 Step
○
○
407
Reverse Speed between 2-3 Step
○
○
408
Ramp Up Time
○
○
409
FreeRun Ramp Down Time
○
○
410
1 Pulse Reverse Speed
○
○
Revolution
[rev]
Current
[%]
500
Freerun Revolutions
○
○
501
Reverse Revolutions between 1-2 Step
○
○
502
Reverse Revolutions between 2-3 Step
○
○
503
Rundown Revolution Low Limit
○
○
504
Rundown Revolution High Limit
○
○
505
Reverse Revolutions before Fastening
○
○
520
No Load Current Limit
○
○
521
Low Current Warning
○
○
522
High Current Warning
○
○
523
Fastening Current Limit
○
○
(Continued on next page)
S0140185-H
