☆ Fastening Result Record
Fastening results data are saved in a nonvolatile memory (EEPROM) inside the Unit (approx. 10,000
sets of data). As curve record data, 100 sets of data are stored in the volatile memory (RAM) inside
the Unit.
As NG (failure) curve record data, 100 sets of data are stored in the nonvolatile memory (EEPROM).
The fastening results data and the NG (failure) curve data are therefore preserved even if the power
is turned off. However, once the power is turned off, the curve record data are initialized and the
previous data are lost when the power is turned on subsequently. The above data can be read with
the User Console software.
●Fastening Result Storage Feature List of HFC3000 System
Function Name
Automatic Save *1
Stored Data
User Console
Fastening
Data
Curve Data
Fastening Data
Setting Tab
Preferences
Auto Upload
Stored Data
Storage Content
Stored Data
Curve Data
Stored Data
Abnormals
Storage Location
PC
Each Controller
Storable Records
-
12000
results
500 results
Setting Item
Yes
No
JUDGMENT
ACCEPT
○
○
○
REJECT
○
○
○
ABNORMAL
○
○
○
○
BYPASS
○
○
○
STOP
○
○
○
RESET
STOP
○
○
○
START OFF
○
○
○
*1：During the data collection in the Fastening Data screen of HFC3000 User Console,
Automatic Save is enabled.
