Chapter 4 Installation
PAGE 4-13
SELF CHECK: TORQUE TRANSDUCER AUTOMATIC CHECK SIGNAL PIN No.: TB1-6
If this signal is “OFF” (or unconnected) when the START signal is input, the home-position voltage
level and the CAL voltage level of the torque transducer are automatically checked before the
fastening process.
If the automatic check of the transducer is not required, fastening without the self-check can be
performed by setting this signal to "ON" when the START signal is input.
WORK SELECT 0 ~ 4: Work Select Signals PIN No.: TB1-7 ~ 11
WORK SELECT 5: Work Select Signals PIN No.: TB3-9
A Work No. among 64 types can be selected by a combination of the signals WORK SELECT 0 ~
WORK SELECT 5.
WORK SELECT 5 signal can be used with Controller software version V1.301 or later.
WORK
SELECT 5
PIN No.:TB3-9
WORK
SELECT 4
PIN No.: TB1-11
WORK
SELECT 3
PIN No.: TB1-10
WORK
SELECT 2
PIN No.: TB1-9
WORK
SELECT 1
PIN No.: TB1-8
WORK
SELECT 0
PIN No.: TB1-7
(Continued on next page)
S0140185-H
