Table 2. DD9910 system features(continued)
Features Single Node HA
Cache SSD shelf FS240 N/A 1
Cache SSDs (2.5% of Active Tier Capacity) 10 x 3.84 TB (internal) 10 x 3.84 TB (external - FS240)
HA Private Interconnect N/A 4 x 10G or 25G ports
NVRAM M.2 NVME Software Defined Persistent
Memory (SDPM)
1 x 64 GB
Internal SAS PowerEdge Raid Controller
(PERC) 12 Gbps SAS
1
External SAS 4-Port 12 Gbps SAS 2 (3 maximum for controller upgrades from older platforms)
SAS String Depth (max) DS600 3
Host interface HBAs 2-port 100 GbE-QSFP28
or 2-port 100 GbE-
QSFP56
4 maximum
4-port 25 GbE-SFP28 4 maximum
4-port 10 GbE-SFP+ 4 maximum
4-port 10GBASE-T 4 maximum
4-port 32 Gb FC 4 maximum
Open Compute Project
(OCP) 3.0 card options
(system will have one of
the two options)
4-port 25 GbE-SFP28 1
4-port 10GBASE-T 1
Locating the Express Service Code and Service Tag
The unique Express Service Code and Service Tag are used to identify the system.
The Express Service Tag is located on the front of the system that includes system information such as the Service Tag,
Express Service Code, Manufacture date, NIC, MAC address, QRL label, and the secure default iDRAC password.
Figure 1. Locating the Express Service Code and Service tag
1. Express Service Tag (front view)
2. Express Service Tag (rear view)
3. OpenManage Mobile (OMM) label - Not used on PowerProtect DD
4. iDRAC MAC address and iDRAC secure password label
5. Service Tag, Express Service Code, QRL label
