Connect Cables and Power On
Topics:
• DD9410 with DS600 cabling
•
DD9910 with DS600 cabling with two SAS I/O modules
• Connecting the HA interconnect
• Connecting data cables
• Connecting disk shelf power cables
• Connecting controller power cables and powering on
DD9410 with DS600 cabling
The diagram shows the system cabled in two sets of two shelves each. The FS240 SSD shelf is cabled as a separate set from
the DS600 shelves.
Table 8. DD9410 with DS600 cabling instructions: Single node or HA primary node
Chain HBA Port Shelf Port Length
a
Cable Color in Cabling
Diagram
1 Slot 3, Port 0 AM 1, Port 4 of shelf V1.2 3M Red
1 Slot 6, Port 0 AM 2, Port 4 of shelf V1.1 3M
2 Slot 3, Port 1 AM 1, Port 4 of shelf V2.2 3M Yellow
2 Slot 6, Port 1 AM 2, Port 4 of shelf V2.1 3M
3 Slot 3, Port 3 AM 1, Port 1 of shelf V3.1 3M Gold
3 Slot 6, Port 3 AM 2, Port 1 of shelf V3.1 3M
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
Table 9. DD9410 with DS600 cabling instructions: HA primary node to FS240
Chain HBA Port Shelf Port Length
a
Cable Color in Cabling
Diagram
3 Slot 3, Port 3 AM 1, Port 1 of shelf V3.1 3M Gold
3 Slot 6, Port 3 AM 2, Port 1 of shelf V3.1 3M
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
Table 10. DD9410 with DS600 cabling instructions: HA standby node (HA only)
Chain HBA Port Shelf Port Length
a
Cable Color in Cabling
Diagram
1 Slot 3, Port 0 AM 1, Port 2 of shelf V1.1 3M Purple
1 Slot 6, Port 0 AM 2, Port 2 of shelf V1.2 3M
2 Slot 3, Port 1 AM 1, Port 2 of shelf V2.1 3M Blue
2 Slot 6, Port 1 AM 2, Port 2 of shelf V2.2 3M
3 Slot 3, Port 3 AM 1, Port 2 of shelf V3.1 3M Gold
3 Slot 6, Port 3 AM 2, Port 2 of shelf V3.1 3M
4
