Dell DD9410 - DD9910 with DS60 Cabling Instructions: DS600 to DS600

Table 15. DD9910 with DS60 cabling instructions: DS600 to DS600
Chain First Shelf Port Second Shelf Port Length
a
Cable Color in Cabling
Diagram
1 AM 1, Port 4 of
shelf V1.1
AM 1, Port 2 of shelf V2.2 3M Green
1 AM 2, Port 2 of
shelf V1.1
AM 2, Port 4 of shelf V2.2 3M
2 AM 1, Port 4 of
shelf V2.1
AM 1, Port 2 of shelf V2.2 3M
2 AM 2, Port 2 of
shelf V2.1
AM 2, Port 4 of shelf V2.2 3M
3 AM 1, Port 4 of
shelf V3.1
AM 1, Port 2 of shelf V3.2 3M
3 AM 2, Port 2 of
shelf V3.1
AM 2, Port 4 of shelf V3.2 3M
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
Connect Cables and Power On 47
