DD9910 with DS600 cabling with two SAS I/O
modules
The diagram shows the system cabled in three sets of two shelves each. The FS240 SSD shelf is cabled as a separate set from
the DS600 shelves.
NOTE: The cabling instructions and diagram are shown with two SAS HBAs.
Table 12. DD9910 with DS600 cabling instructions: Single node or HA primary node
Chain HBA Port Shelf Port Length
a
Cable Color in Cabling
Diagram
1 Slot 3, Port 0 AM 1, Port 4 of shelf V1.2 3M Red
1 Slot 6, Port 0 AM 2, Port 4 of shelf V1.1 3M
2 Slot 3, Port 1 AM 1, Port 4 of shelf V2.2 5M Pink
2 Slot 6, Port 1 AM 2, Port 4 of shelf V2.1 5M
3 Slot 3, Port 2 AM 1, Port 4 of shelf V3.2 3M Yellow
3 Slot 6, Port 2 AM 2, Port 4 of shelf V3.1 3M
4 Slot 3, Port 3 AM 1, Port 1 of shelf V4.1 3M Gold
4 Slot 6, Port 3 AM 2, Port 1 of shelf V4.1 3M
a.
Cable lengths shown are designed for racks. Longer cables (up to 5M) can be used.
Table 13. DD9910 with DS600 cabling instructions: HA primary node to FS240
Chain HBA Port Shelf Port Length
a
Cable Color in Cabling
Diagram
4 Slot 3, Port 3 AM 1, Port 1 of shelf V4.1 3M Gold
4 Slot 6, Port 3 AM 2, Port 1 of shelf V4.1 3M
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
Table 14. DD9910 with DS600 cabling instructions: HA standby node (HA only)
Chain HBA Port Shelf Port Length
a
Cable Color in Cabling
Diagram
1 Slot 3, Port 0 AM 1, Port 2 of shelf V1.1 3M Purple
1 Slot 6, Port 0 AM 2, Port 2 of shelf V1.2 3M
2 Slot 3, Port 1 AM 1, Port 2 of shelf V2.1 3M Pale Green
2 Slot 6, Port 1 AM 2, Port 2 of shelf V2.2 5M
3 Slot 3, Port 2 AM 1, Port 2 of shelf V3.1 5M Blue
3 Slot 6, Port 2 AM 2, Port 2 of shelf V3.2 3M
4 Slot 3, Port 3 AM 1, Port 2 of shelf V4.1 3M Gold
4 Slot 6, Port 3 AM 2, Port 2 of shelf V4.1 3M
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
46 Connect Cables and Power On
