Dell DD9410 - DD9410 with DS600 Cabling Instructions: DS600 to DS600

Table 10. DD9410 with DS600 cabling instructions: HA standby node (HA only)
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
Table 11. DD9410 with DS600 cabling instructions: DS600 to DS600
Chain First Shelf
Port
Second Shelf Port Length
a
Cable Color in
Cabling Diagram
1 AM 1, Port 4
of shelf V1.1
AM 1, Port 2 of shelf V2.2 3M Green
1 AM 2, Port 2
of shelf V1.1
AM 2, Port 4 of shelf V2.2 3M
2 AM 1, Port 4
of shelf V2.1
AM 1, Port 2 of shelf V2.2 3M
2 AM 2, Port 2
of shelf V2.1
AM 2, Port 4 of shelf V2.2 3M
a.
Cable lengths shown are designed for Dell racks. Longer cables (up to 5M) can be used.
