NOTE: This step is not required when adding a new disk pack to an existing DS600.
NOTE: Optionally run the enclosure test topology command to test each SAS path.
4. Run the disk show state command to verify the system can see all the disks in the new enclosure. All the new disks
should display in the Unknown state.
●
For a new disk pack in an existing DS600:
# disk show state
Enclosure Disk
Row(disk-id) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24
--------------
-------------------------------------------------------------------------------------
1 . . . . .
. . . .
2 |--------|--------|--------|--------|
| Pack 1 | Pack 2 | Pack 3 | Pack 4 |
E(49-60) |. . s |U U U |- - - |- - - |
D(37-48) |. . . |U U U |- - - |- - - |
C(25-36) |. . . |U U U |- - - |- - - |
B(13-24) |. . . |U U U |- - - |- - - |
A( 1-12) |. . . |U U U |- - - |- - - |
|--------|--------|--------|--------|
-------------- ----------------------------------------------
Legend State Count
------ ------------------- -----
. In Use Disks 23
U Unknown Disks 15
s Spare Disks 1
- Not Installed Disks 30
------ ------------------- -----
Total 39 disks
● For a new DS600:
# disk show state
Enclosure Disk
Row(disk-id) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24
--------------
-------------------------------------------------------------------------------------
1 . . . . .
. . . .
2 |--------|--------|--------|--------|
| Pack 1 | Pack 2 | Pack 3 | Pack 4 |
E(49-60) |. . . |. . . |. . . |. . . |
D(37-48) |. . . |. . . |. . . |. . . |
C(25-36) |. . . |. . . |. . . |. . . |
B(13-24) |. . . |. . . |. . . |. . . |
A( 1-12) |. . s |. . s |. . s |. . s |
|--------|--------|--------|--------|
3 |--------|--------|--------|--------|
| Pack 1 | Pack 2 | Pack 3 | Pack 4 |
E(49-60) |U U U |- - - |- - - |- - - |
D(37-48) |U U U |- - - |- - - |- - - |
C(25-36) |U U U |- - - |- - - |- - - |
B(13-24) |U U U |- - - |- - - |- - - |
A( 1-12) |U U U |- - - |- - - |- - - |
|--------|--------|--------|--------|
-------------- ----------------------------------------------
Legend State Count
------ ------------------- -----
. In Use Disks 65
U Unknown Disks 15
s Spare Disks 4
- Not Installed Disks 45
------ ------------------- -----
Total 84 disks
Add Storage Capacity
