Dell E60S - Removing a 2.5-Inch Drive from the 3.5-Inch Drive Adapter

Figure 33. Installing a drive into the drive carrier
Next steps
1. Replace the drive carrier.
2. Install the front bezel.
3. Follow the procedure listed in After working inside your system.
Removing a 2.5-inch drive from the 3.5-inch drive adapter
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove 3.5-inch drive adapter from the 3.5-inch drive carrier.
NOTE:
A 2.5 inch hot swappable drive is installed in a 3.5-inch drive adapter, which is then installed in the 3.5-inch hot
swappable drive carrier.
Steps
1. Using a Phillips #1 screwdriver, remove the screws from the side of the 3.5-inch drive adapter.
NOTE: If the 2.5-inch drive has Torx screw, use Torx 6 screwdriver to remove the drive from a 3.5-inch drive adapter.
2. Remove the drive from the 3.5-inch drive adapter.
Installing and removing system components
37
