Dell E60S - Installing a 2.5-Inch Drive into the 3.5-Inch Drive Adapter

Figure 34. Removing a 2.5-inch drive from the 3.5-inch drive adapter
Next steps
Replace a 2.5-inch drive into the 3.5-inch drive adapter.
Installing a 2.5-inch drive into the 3.5-inch drive adapter
Prerequisites
Follow the safety guidelines listed in Safety instructions.
Steps
1. Align the screw holes on the 2.5-inch drive with the screw holes on the 3.5-inch drive adapter.
2. Using a Phillips #1 screwdriver, install the screws to secure the drive to the 3.5-inch drive adapter.
NOTE: If the 2.5-inch drive has Torx screw, use Torx 6 screwdriver to install the drive to a 3.5-inch drive adapter.
38 Installing and removing system components
