ISCSI TLV Tx Status is disabled
Local FCOE PriorityMap is 0x8
Local ISCSI PriorityMap is 0x10
Remote FCOE PriorityMap is 0x8
Remote ISCSI PriorityMap is 0x8
0 Input TLV pkts, 1 Output TLV pkts, 0 Error pkts, 0 Pause Tx pkts, 0 Pause Rx pkts
The following table describes the show interface pfc summary command elds.
Table 21. show interface pfc summary Command Description
Fields Description
Interface Interface type with stack-unit and port number.
Admin mode is on; Admin is enabled PFC Admin mode is on or o with a list of the congured PFC
priorities . When PFC admin mode is on, PFC advertisements are
enabled to be sent and received from peers; received PFC
conguration takes eect. The admin operational status for a DCBx
exchange of PFC conguration is enabled or disabled.
Remote is enabled; Priority list Remote Willing Status is enabled Operational status (enabled or disabled) of peer device for DCBx
exchange of PFC conguration with a list of the congured PFC
priorities. Willing status of peer device for DCBx exchange (Willing
bit received in PFC TLV): enabled or disabled.
Local is enabled DCBx operational status (enabled or disabled) with a list of the
congured PFC priorities
Operational status (local port) DCBx operational status (enabled or disabled) with a list of the
congured PFC priorities.
Port state for current operational PFC conguration:
• Init: Local PFC conguration parameters were exchanged with
peer.
• Recommend: Remote PFC conguration parameters were
received from peer.
• Internally propagated: PFC conguration parameters were
received from conguration source.
PFC DCBx Oper status Operational status for exchange of PFC conguration on local port:
match (up) or mismatch (down).
State Machine Type Type of state machine used for DCBx exchanges of PFC
parameters:
• Feature: for legacy DCBx versions
• Symmetric: for an IEEE version
TLV Tx Status Status of PFC TLV advertisements: enabled or disabled.
PFC Link Delay Link delay (in quanta) used to pause specied priority trac.
Application Priority TLV: FCOE TLV Tx Status Status of FCoE advertisements in application priority TLVs from
local DCBx port: enabled or disabled.
Application Priority TLV: ISCSI TLV Tx Status Status of ISCSI advertisements in application priority TLVs from
local DCBx port: enabled or disabled.
Application Priority TLV: Local FCOE Priority Map Priority bitmap used by local DCBx port in FCoE advertisements in
application priority TLVs.
