Delta VFD-L Series User Manual

VFD-L Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-6
Group 7: Motor Parameters
Parameter
s
Functions Settings
Factor
y
Settin
g
=
7-00 Motor rated current 30~120 % 85
=
7-01 Motor no-load current 0 ~ 90 % 50
=
7-02 Torque compensation 0 ~ 10 1
=
7-03 Slip compensation 0.0 ~ 10.0 0.0
Group 8: Special Parameters
Parameter
s
Functions Settings
Factor
y
Settin
g
8-00 DC braking voltage lev
el
0 ~ 30% 0
8-01
DC braking time during
start-up
0.0 ~ 60.0 Sec 0.0
8-02
DC braking time during
stopping
0.0 ~ 60.0 Sec 0.0
8-03
Start-point for DC
braking
0.0 ~ 400.0 Sec 0.0
8-04 Momentary power loss
0: Stop operation after momentary
power loss.
1: Continues after momentary power
loss, speed search starts with maste
r
freq.
2: Continues after momentary power
loss, speed search starts with min.
output freq.
0
8-05
Max. allowable power
loss time
0.3 ~ 5.0 Sec 2.0
8-06
B.B. time for speed
search
0.3~5.0 Sec 0.5
8-07
Max. speed search
current level
30~200% 150
8-08 Skip freq. 1 upper boun
d
0.0~400 Hz 0.0
8-09 Skip freq. 1 lower boun
d
0.0~400 Hz 0.0
8-10 Skip freq. 2 upper boun
d
0.0~400 Hz 0.0
8-11 Skip freq. 2 lower boun
d
0.0~400 Hz 0.0
8-12 Skip freq. 3 upper boun
d
0.0~400 Hz 0.0
8-13 Skip freq. 3 lower boun
d
0.0~400 Hz 0.0

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
