5.4 Cable recommendations MATRIX.Net
We recommend the following data transfer cable for MATRIX.Net bus system:
5.5 Disassembly of the MATRIX control panel OP71
• Isolate the air treatment units and in such a way the MATRIX control panel OP71.
Total max. line length
[m]
Max. line length with
branch feeders, total
[m]
Manufacturer Cable type only
MATRIX.Net
MATRIX.Net + supply
voltage
50 50 LAPP cable UNITRONIC
®
BUS CAN 1x2x0.22 2x2x0.22
300 150 LAPP cable UNITRONIC
®
BUS CAN 1x2x0.34 2x2x0.34
600 150 LAPP cable UNITRONIC
®
BUS CAN 1x2x0.5 2x2x0.5
30 30 LAPP cable UNITRONIC
®
BUS LD 1x2x0.22 2x2x0.22
30 30 LAPP cable UNITRONIC
®
Li2YCY (TP) 2x2x0.22
150 60 LAPP cable UNITRONIC
®
Li2YCY (TP) 1x2x0.34 2x2x0.34
150 60 LAPP cable UNITRONIC
®
Li2YCY (TP) 1x2x0.5 2x2x0.5
30 30 LAPP cable UNITRONIC
®
Li2YCY PiMF 2x2x0.22
300 150 LAPP cable UNITRONIC
®
Li2YCY PiMF 2x2x0.34
600 150 LAPP cable UNITRONIC
®
Li2YCY PiMF 2x2x0.5
50 50 HELUKABEL CAN BUS 1x2x0.22 4x1x0.22
300 150 HELUKABEL CAN BUS 1x2x0.34 4x1x0.34
600 150 HELUKABEL CAN BUS 1x2x0.5 4x1x0.5
30 30 HELUKABEL PAAR-TRONIC-Li-2YCYV 2X2X 2x2x0.22
30 30 BELDEN 9841 1x2xAWG24
30 30 BELDEN 9842 2x2xAWG24
150 60 BELDEN 3105A 1x2xAWG22
150 60 BELDEN 3107A 2x2xAWG22
Electrical hazard!
The MATRIX control panels OP71 are connected to the power supply of the air
treatment units. Therefore, the control panel itself can not be powered down!
Switch off the power to the air treatment units and make sure they are isolated,
earth and short-circuit them, block off or shield any neighboring or live com-
ponents.
Non-compliance can lead to death or serious injury.
