10 Menu Structure OP71
All possible menus are shown in this menu structure. According to the configuration of the controller some menus can
exclude one another or not appear at all.
1) This menu is not available if MATRIX 4700 controls is used for standard and low-profile air handling units.
2) This menu is only available if MATRIX 4700 controls is used with standard and low-profile air handling units.
Cluster Selec-
tion
0: Cluster 0 ...
F: Cluster F
Cluster or rat-
her
All Clusters
Standard value room
temperature
(
✟↔ 47)
Change setpoint in °
Setpoint supply air tem-
perature (✟↔ 48)
Change setpoint in °
Settings for fan speed
(✟↔ 49)
Select Menu
Fan mode
(✟↔ 49)
OFF
Automatic
Automatic (mute)
Speed xx % or stage x
Plant/fan
(
✟↔ 51)
OFF
ON
Fan speed (✟↔ 51)
Speed xx %
Supply-air duct pres-
sure/
extract-air duct pres-
sure (✟↔ 52)
Pressure in Pa
Supply air volume flow/
Extract air volume
flow(
✟↔ 53)
Volume flow in m³/h
Operating mode
(✟↔ 53)
Std-by
Normal operation
Economy mode
Clock Timer
Preference
Controller mode
(✟↔ 55)
Heating only
Cooling only
Automatic
Passive Cooling
Mixing-air damper posi-
tion / Mixing-air damper
mode (
✟↔ 55)
Mixing-air damper posi-
tion in percent or
mixing-air damper
mode recirculating air/
mixed air
Outside air flow
(
✟↔ 56)
Air volume flow in %
Basic Ventilation
(✟↔ 56)
ON
Automatic
Fast Ventilation
(✟↔ 56)
Duration in minutes
Outside air automatic
(✟↔ 56)
Recirculating air
Mixed air automatic
To Next Page
