Menu Structure OP71 MATRIX Control Panel OP71
96 PR-2009-0021-GB • Subject to modifications • R5-04/2016

Other menus
(✟↔ 57)

Actual values (✟↔ 57)

Select group 0
...
group F

Room temperature
Outdoor temperature
Supply-air temperature
Inlet temperature
Evaporation tem-
perature
ERS temperature
Relative humidity in
room
Relative humidity out-
side
CO2 air quality
Mixing-air damper posi-
tion

Settings (✟↔ 58)

economy mode
(✟↔ 58)

room tem-
perature(✟↔ 59) (x °)

Supply-air temperature
(✟↔ 59) (x °)

Fan speed
(✟↔ 59)(Menus: fan
mode, plant/fan, Menu
plant/fan + Menu fan
speed, Menu plant/fan
+ Menu supply air/ext-
ract-air duct pressure,
Menu plant/fan + Menu
supply air/extract-air
volume flow)

Fan mode (✟↔ 60)
(OFF, automatic, auto
(low-noise), speed xx
%/speed x)

Plant/fan
(✟↔ 60)
(OFF, ON)

Fan speed (✟↔ 61)
(x %)
